2*10T/H Fish Feed & 5T/H Shrimp Feed Mill in India

This is a high-end 2*10t/h fish feed & 5t/h shrimp feed mill in India, is designed with 4 production lines, with an annual output of 200,000 tons of fish, shrimp, and livestock feed (including 150,000 tons/year of livestock feed, 10,000 tons/year of high-grade shrimp feed, and 40,000 tons/year of high-grade extruded fish feed).

 2*10T/H Fish Feed & 5T/H Shrimp Feed Mill in India

OVERVIEW

This is a high-end 2*10t/h fish feed & 5t/h shrimp feed mill in India, also combined with poultry and livestock feed production line project. The product types cover high-end fish extruded pellet feed, high-end shrimp pellet feed, and high-end livestock and poultry feed.

The large animal and aqua feed mill in India project is designed with 4 production lines, with an annual output of 200,000 tons of fish, shrimp, and livestock feed (including 150,000 tons/year of livestock feed, 10,000 tons/year of high-grade shrimp feed, and 40,000 tons/year of high-grade extruded fish feed).

  • Name:

    Poultry Livestock Aqua Fish Shrimp Feed Plant

  • Country:

    India

  • Date:

    December 2022

  • Capacity:

    200,000 t/a

  • Feed Size:

    1-8mm

  • The install period:

    15 Months

  • Control Mode:

    Automatic

  • Guiding Price:

    3 million USD

 2*10T/H Fish Feed & 5T/H Shrimp Feed Mill in India

The construction content of this 2*10t/h fish feed & 5t/h shrimp feed mill in India project includes production workshop, raw material workshop, finished product workshop and supporting projects, and the installation of production equipment.

The process during the construction period of this 2*10t/h fish feed & 5t/h shrimp feed plant in India project includes basic engineering, structural engineering, equipment installation and commissioning, and acceptance and commissioning.

Construction content and scale

Construction content and scale

This 2*10t/h fish feed & 5t/h shrimp feed mill in India project covers a total area of 16,253 m2, with a total construction area of 6,093.6 m2, and an annual output of 200,000 tons of fish, shrimp, and poultry and livestock feed (including 150,000 tons of poultry and livestock feed per year, and 10,000 tons of high-grade shrimp feed per year) , high-grade extruded fish feed 40,000 tons/year).

This large compound feed mill project will build a total of 4 feed pellet production lines: 1 5t/h fish and shrimp feed production line, 2 10t/h expanded fish feed production lines, and 1 15t/h poultry and livestock feed production line.

The main construction contents of this large capacity 2*10t/h fish feed & 5t/h shrimp feed mill in India project are shown in the table below:

Project name Project scale
Production workshop 6 floors, covering an area of 588m2, 4 production lines
Finished product workshop 1 floor, covering an area of 1710m2
Office building 3 floors, covering an area of 133.5m2
Doorman 1 floor, covering an area of 12m2
Weighbridge Covers an area of 63m2
Dormitory 3 floors, covering an area of 133.5m2
Raw material workshop 1 floor, covering an area of 2217m2
Raw materials warehouse 1st floor, steel structure, covering an area of 313.2m2
Finished product loading canopy 1 floor, covering an area of 326.4m2
Raw oil tank 3
Raw material unloading truck canopy 1 floor, covering an area of 126m2

About the general layout:

The factory area of this 2*10t/h fish feed & 5t/h shrimp feed mill in India project consists of office and living area, raw material workshop, finished product workshop, and production workshop from north to south.

The entrance and exit are located between the raw material trucks and the finished product workshop, which facilitates the transportation of raw materials and finished products. The entire layout is relatively reasonable and there is little logistics crossover.

Equipment to start the livestock poultry shrimp fish feed mill in India

Number Device name QTY
1 Pulse dust collector 3
2 Fan 3
3 Scraper machine 3
4 Bucket elevator 15
5 Cylindrical primary cleaning screen 3
6 Pulse dust collector 3
7 Permanent magnet cylinder 6
8 Distributor 7
9 Crusher impeller feeder 3
10 New Era Crusher 3
11 Pulse dust collector 3
12 Material sealing screw conveyor 3
13 High pressure blower 3
14 Out of warehouse machine 8
15 Out of warehouse machine 18
16 Out of warehouse machine 6
17 Pneumatic butterfly valve 4
18 Ingredients scale 4
19 Ingredients scale door 4
20 Pneumatic round tee 12
21 Review scale 2
22 Paddle mixer 1
23 Paddle mixer 3
24 Vibrating air hammer 12
25 Scraper conveyor 3
26 Scraper conveyor 4
27 Hoist 3
28 Sensor 12
29 Pneumatic gate 4
30 Single shaft mixer 1
31 Pneumatic butterfly valve 3
32 High pressure blower 3
33 Drawer sieve 3
34 Ingredients scale 1
35 Pneumatic butterfly valve 2
36 Feeding auger 2
37 Conditioner 2
38 Preserver 2
39 Animal feed pelle machine 2
40 Eccentric air shutter 2
41 Slide cooler 2
42 Cyclone 2
43 Fan 2
44 Air shut-off device 2
45 Crusher 1
46 Bucket elevator 1
47 Grading screen 2
48 Vibrating grading screen 1
49 Granular electronic packaging scale 2
50 Belt conveyor sewing machine 1
51 Round broken arch feeding bin 1
52 Eccentric air shutter 1
53 Aging and drying combination 1
54 Cyclone 1
55 Fan 1
56 Drawer sieve 1
57 Electronic packing scale 2
58 Belt conveyor sewing machine 2
59 Pellet Crumbler 1
60 High square sieve 3
61 Round broken arch feeding bin 1
62 Feeding auger 1
63 Dual-axis differential conditioner DDC 1
64 Single axis conditioner 1
65 Floating fish feed machine 1
66 Air shut-off device 1
67 Fan 1
68 Cyclone 1
69 Fan 1
70 Eccentric air shutter 1
71 Aqua feed dryer 1
72 Cyclone 1
73 Fool grading screen 2
74 Differential weight grease spraying machine 1
75 Eccentric air shutter 1
76 Flip cooler 1
77 Cyclone 1
78 Cooling fan 1
79 Air compressor 2
80 Filter 2
81 Gas tank 1
82 Freeze dryer 1
83 Liquid scale 4
84 Water adding machine 1
85 Grease intermediate tank 5

Main raw and auxiliary materials

Raw materials for India floating fish feed production line

Name of raw materials and excipients Annual usage (t/a) Packaging specifications
Fishmeal 3000 50kg
Soybean meal 13000 60kg
Flour 6400 25kg
Rapeseed meal 5000 50kg
DDGS (dry distillers grains) 8400 Bulk
Premix 1600 40kg
Calcium dihydrogen phosphate 600 50kg

Raw materials for India shrimp feed processing line

Name of raw materials and excipients Annual usage (t/a) Packaging specifications
Fishmeal 2500 50kg
Soybean meal 3000 60kg
Flour 2000 25kg
Peanut meal 1500 50kg
Premix 400 40kg
Calcium dihydrogen phosphate 200 50kg
Fish oil 400 Bulk

Raw materials for India poultry livestock feed production line

Name of raw materials and excipients Annual usage (t/a) Packaging specifications
Corn 62000 Bulk
Soybean meal 37500 60kg
Rapeseed meal 22500 50kg
DDGS (dry distillers grains) 15000 Bulk
Wheat 6000 Bulk
Premix 6000 40kg
Calcium dihydrogen phosphate 3000 50kg

India fish shrimp feed mill Process design

This 2*10t/h fish feed & 5t/h shrimp feed mill in India project mainly produces 150,000 tons of poultry and livestock feed per year, 10,000 tons of high-grade shrimp feed per year, and 40,000 tons of high-grade extruded fish feed per year.

Brief description of the overall animal aqua fish shrimp feed production process:

  1. Raw material receiving system:
    Design three feeding ports, and set up a bag dust removal system to improve the working environment.
  2. Coarse crushing system:
    Design three hammer mill crushers to coarsely crush all raw materials to improve the efficiency of ultrafine powder.
  3. Primary batching mixing system:
    The batching system is designed with 18 batching bins, equipped with mixers and batching scales, and the mixers are equipped with return air systems.
  4. Clean the (ultra-fine) grinding system:
    Design 4 sets of 150-type ultra-fine grinders to crush shrimp feed and puffed fish feed, small pellet feed and high-grade floating fish pellet feed. The grinding fineness is higher. The use of ultra-fine grinding can improve the feed quality.
  5. Secondary batching mixing system:
    One batching system is designed for secondary batching. Fish feed and shrimp feed are mixed twice to improve the uniformity of ultra-finely crushed materials. The mixer is equipped with a return air system to reduce the impact of negative pressure in the mixer on the batching accuracy. In this section, grease can be added to increase the grease content of the finished product.
  6. Pelleting and maturation:
    Pelleting is the process of compacting the mixed powder through mechanical action and extruding it out of the die holes to form granular feed. The powdery raw materials in the granulation bin enter the conditioner through the feeder at the bottom of the bin.
    At the same time, steam will also flow into the conditioner. After the raw materials come into contact with high-temperature steam, the temperature rises rapidly to 78-83°C, and the moisture content rises to about 16.5%.
    After the raw materials are conditioned, they become soft due to the absorption of heat and moisture in the steam, which is conducive to granulation and forming.
    At the same time, after high-temperature treatment, most harmful microorganisms in the raw materials have been killed and the raw materials have matured, which is beneficial to reducing animal morbidity and improving the digestion and absorption rate of feed.
  7. Extrusion and drying system:
    Choose a bedroom dryer. This aqua fish feed dryer is the latest type of dryer machine. It has the characteristics of high drying efficiency, energy saving, low failure rate; uniform moisture; stable drying temperature and other characteristics.
  8. Screening and spraying system:
    Use roller spraying, spraying evenly, no flowers and scraps, no waste, controllable, no pollution to the workshop environment.
  9. Cooling and crumbling:
    The cylindrical feed enters the counterflow pellet cooler and is cooled by air. The temperature of the cooled feed is controlled within the range of ambient temperature +5.5°C. The cooled pellet feed has a large particle size and is not suitable for direct consumption by animals. It needs to be crushed by a pellet crumbler first.
  10. Screening and finished product packaging system:
    The crumbled feed enters the screening machine for screening, the feed with qualified particle size goes to the finished product warehouse, and the feed with too large and too small particle size is recycled. Qualified finished products enter the automatic packaging system for weighing and packaging.

Brief description of the production process of India poultry and livestock feed mill

  1. Corn, soybean meal, rapeseed rice, wheat and other raw materials are first cleaned through a cleaning screen and then crushed by a crusher.
  2. The crushed raw materials are batched and weighed according to the preset feed formula requirements, using a specific batching and measurement system for different types of feed raw materials.
  3. The prepared materials are sent to the mixing equipment, and then the premix, grease, and water are weighed and mixed according to the formula proportions.
  4. After the mixture enters the livestock poultry feed pellet machine, it produces granular compound feed whose nutritional content and mixing uniformity meet the qualified product standards.
  5. The pellets are crushed after cooling.
  6. After the crushed materials pass the finished product screening inspection, they are packed by a baler and stored in the warehouse for external sale; the coarse particles are returned to the previous crushing link, and the fine powder is returned to the granulation link.

Brief description of the production process of India fish feed mill:

  1. Raw materials such as meal are first cleaned through a cleaning sieve, and then crushed through a pulverizer.
  2. The pulverized raw materials shall be batched and weighed at one time according to the preset feed formula requirements and using a specific batching and measurement system for different types of feed raw materials.
  3. The prepared materials are sent to the mixing equipment for primary mixing.
  4. After primary mixing, perform secondary crushing + secondary mixing.
  5. The mixture enters the extruder and is expanded to produce granular compound feed whose nutritional content and mixing uniformity meet qualified product standards.
  6. After drying, the pellets are sprayed with grease and then cooled.
  7. After cooling, the pellets pass the finished product screening test and then enter the charter machine for packaging and storage for external sale; the fine powder is screened and returned to the primary ingredient mixing process; the coarse particles return to the cleaning and crushing process.

Brief description of the production process of high-grade shrimp feed mill:

  1. Raw materials such as meal are first crushed by a crusher.
  2. The pulverized raw materials shall be batched and weighed at one time according to the preset feed formula requirements and using a specific batching and measurement system for different types of feed raw materials.
  3. The prepared materials are sent to the mixing equipment for primary mixing.
  4. After primary mixing, perform secondary crushing + secondary mixing.
  5. The mixture enters the shrimp feed granulator for pelleting and maturation processing to produce granular compound feed whose nutritional content and mixing uniformity meet qualified product standards.
  6. After cooling, the pellets are crushed and then enter the screening machine. The qualified products screened out are weighed and packaged by the charter machine and stored in the warehouse for external sale; the fine powder is screened and returned to the primary ingredient mixing process; the coarse particles are returned to cleaning and crushing link.

Why start fish feed & shrimp feed mill in India?

As a large maritime country, India's fishery output value has always been among the best in the world, and India's fishery export volume ranks first in the world.

In recent decades, India has invested 2,050 billion rupees (approximately US$246 million) in inland aquaculture, and inland aquaculture production has reached 13.1 million tons, doubling in the past nine years.

India accounts for 8% of global fish production and is the second largest aquaculture producer, the third largest fish producer and the fourth largest exporter of seafood. Aquaculture is one of the key pillars of global food security and serves millions of people. Farmers provide livelihoods and meet the growing demand for protein.

It can be clearly seen that the strong development of the aquaculture industry in India has incomparable traditional advantages in both fish farming and shrimp farming. Correspondingly, the fish feed and shrimp feed processing industries will also develop in proportion.

Tips for Starting a fish feed & shrimp feed mill in India

Market of the target

Evaluate the possibilities of the fish shrimp feed production line you choose thoroughly. It is important to narrow it down to a certain market, and manufacturing food for animals of all kinds could not be the best idea.

Manufacturing methods for shrimp fish feed food items are not even like the livestock, poultry, and pet food products. Your market will be too fast-paced. Three are highly sought-after and a plan that has three as the primary focus will bring more market potential across the world.

A Comprehensive Market Research

Conduct market research about the aqua fish shrimp and other animals that live in India area. If you plan to market your idea to an investor, then you need to present the uniqueness of your strategy in comparison to other competitors.

Pick the most attractive market segment for your area and calculate your revenue projections, by setting your initial market share.

Personnel and Equipment

The investment in the fish feed & shrimp feed mill plan will concentrate on the equipment and the plant as the largest expense for the beginning costs. You must invest in top-quality equipment to produce high-quality aqua feeds.

You can also consider investing in custom equipment to meet your requirements, which calls for greater investment. Alternatively, you can seek an expert's advice on the equipment for the fish feed & shrimp feed plant you require before setting up your budget.

Location

A sound aqua fish shrimp feed business plan identifies the plant closest to customers. Additionally, you should want your business to be close to the feed suppliers you have as you can, the further you are away from your customers, the more expensive your distribution costs and marketing cost.

The Raw Materials as well as Suppliers

It is crucial to plan bulk-purchasing during harvest season for plant-based products for the most affordable prices. In the shrimp and fish feed mill business plans, it is essential to describe your source of materials and potential suppliers following the market assessment.

Aqua Feed Formula

Aqua feeds that are not of the highest quality in any industry can put your company out of business, or create legal issues for your startup, a strong formula for feedings will allow for an affordable budget for professional advice in the formula's creation along with employee training.

If you have confidence in Indian aquaculture and see its long-term development, feel free to contact Richi Machinery to customize your aquatic fish feed & shrimp feed mill in India solution and obtain professional technical support.
