3-4 T/H Tofu Cat Litter Making Machine in New Zealand

• Annual output: 7600 tons/year
• Project nature: New construction
• Project investment: US$250,000
• Number of employees: 10
• Working system: Implement a single-shift working system, each shift works 8 hours, and the annual working time is 300 days.
• Rational layout: The overall layout of this 3-4 t/h cat litter making machine in New Zealand project is strictly in accordance with the "Code for Fire Protection in Architectural Design"; the warehouses are arranged on both sides of the production workshop, with short and smooth material transportation, and the building layout is centralized to meet safety, sanitation, fire protection, Transportation and other regulatory requirements.

Construction Content

The total area of the factory area of this 3-4 t/h cat litter making machine in New Zealand project is 1768m2. This project mainly uses 2 workshops and 3 warehouses for renovation. The project composition is shown in the following table:

Raw and auxiliary materials and dosage

The main raw and auxiliary materials of this 3-4 t/h cat litter making machine in New Zealand project are shown in the following table:

Remarks: Guar gum is a water-soluble polymer, a natural hydrophilic colloid of macromolecules. Its appearance is a free-flowing powder from white to slightly yellow. It can be dissolved in cold or hot water and forms a gel when exposed to water. substance to achieve rapid thickening effect. The composition of guar gum generally contains 75% to 85% polysaccharide, 8% to 14% water, 5% to 6% crude protein, 2% to 3% crude fiber and 0.5% to 1% ash.

Process design of 3-4 t/h cat litter making machine in New Zealand

Brief description of cat litter production process:

The tofu fiber, corn flour, starch, guar gum and water are conveyed by wind power and sent to the mixer through the elevator (closed type) for mixing and mixing. Then they flow into the silo through the bottom outlet and are transported into the granules through the silo mixing cage.

The granules are extruded by the machine into long strips. At this time, the granules are in a soft and water-containing state and do not produce floating dust. They are transported to the drying unit by the conveyor belt. After drying, they are cooled and transported to the vibrating screen for screening.

Unqualified products pass through the lower screen. Mesh screening, recycling and reuse from the bottom outlet, the finished particles are transported to the automatic packaging machine for packaging, and the production is completed.

1. Material preparation
   The main raw material of 3-4 t/h cat litter making machine in New Zealand is tofu residue, and also includes a small amount of corn starch, sawdust, cellulose and other auxiliary materials. These materials need to be mixed in a certain proportion and then ground.
2. Grinding
   After the materials are mixed, they need to be ground by a machine to make the materials softer and more delicate for subsequent processing and shaping. At the same time, impurities can also be removed and the purity of the ground material can be improved.
3. Processing and forming
   The ground material needs to be processed and shaped. First, the material needs to be compressed and formed into a block. The block material is then cut into small pieces or granules by a machine for subsequent drying and packaging.
4. Drying
   The processed tofu cat litter needs to be dried to remove the moisture in the material. Usually the drying temperature is controlled at about 130 degrees Celsius and the drying time is about 2 hours. The dried tofu cat litter appears brown or yellow in color and has a hard texture.
5. Packaging
   The dried tofu cat litter needs to be packaged for storage and transportation. Usually packed in plastic bags, each bag weighs 5-10 kg. During the packaging process, the working environment needs to be kept clean to prevent impurities from entering the tofu cat litter.

All in all, the production process of tofu cat litter is divided into five links: material preparation, grinding, processing and shaping, drying and packaging. During the entire production process, attention must be paid to keeping the production environment clean and hygienic to avoid contamination by impurities.

In addition, the R&D and production technology of 3-4 t/h cat litter making machine in New Zealand are constantly improving and innovating to improve product quality and performance.

Major equipment for 3-4 t/h cat litter making machine in New Zealand

The main equipment required for this 3-4 t/h cat litter making machine in New Zealand project is shown in the table below.

Public supporting projects

Water supply

The water for this 3-4 t/h cat litter making machine in New Zealand project is collected from groundwater and relies on existing wells in the factory area. The water used in this project is mainly domestic water and production water.

Domestic water: This project has a working capacity of 10 people and works 300 days per year. The per capita domestic water consumption is calculated as 50L/d per person, then the domestic water consumption is 0.5m3/d and 150m3/a.

Production water: The production water in this 3-4 t/h cat litter making machine in New Zealand project is mainly used as ingredients for cat litter production. The water consumption for cat litter production is 40L/ton of product.

This project has an annual output of 7,600 tons of cat litter, so the water consumption for batching is equivalent to 1.216m3/d, 304m3/a. 80% of the water used for ingredients is lost during the drying process, and 20% enters the product. Therefore, the fresh water consumption of this project is 1.716m3/d, 454m3/a.

Drainage

The factory area implements a rainwater and sewage diversion system for drainage, and rainwater is discharged through the rainwater pipe network. The wastewater in this 3-4 t/h cat litter making machine in New Zealand project is mainly domestic sewage.

The pollution production coefficient of domestic sewage is calculated according to 0.8, then the production volume of domestic sewage is 0.4m3/d, 125m3/a. The main pollutants are COD, ammonia nitrogen, and total nitrogen, and their production concentrations are 350mg/L and 30mg/L respectively. and 45mg/L.

Power supply

The power supply of this 3-4 t/h cat litter making machine in New Zealand project is drawn from the municipal power grid, and the power supply is sufficient to meet the needs of project construction and production.

The electrical equipment used in this project mainly includes machinery equipment and lighting equipment. The annual electricity consumption of this project is approximately 100,000 kW·h.

Heating and ventilation design

This 3-4 t/h cat litter making machine in New Zealand project uses air conditioning for office heating, ventilation in the workshop mainly through doors and windows, and liquefied petroleum gas as the heat source for drying.

Environmental protection measures

Analysis of atmospheric environmental impact

The dust generated by the loading and mixing of this 3-4 t/h cat litter making machine in New Zealand project is collected by the gas collecting hood, and the drying dust and liquefied petroleum gas combustion exhaust gas are uniformly entered into a set of bag dust collectors for processing, and are discharged through a 15m exhaust pipe.

Acoustic environment impact analysis

The high-noise equipment in this 3-4 t/h cat litter making machine in New Zealand project mainly includes elevators, mixers, cat litter pellet machines, dryers, fans, etc., with sound pressure levels of 75 to 80dB(A). Noise pollution prevention and control measures:

1. Control the sound source and select equipment with low noise and in compliance with national noise standards. Reduce vibration and enhance routine maintenance of equipment.
2. The overall layout of the workshop is coordinated and reasonably laid out, and all equipment is arranged indoors.
3. Arrange working time reasonably and do not arrange processing procedures at night.
4. The project strengthens the sealing of workshop doors and windows during the production process to increase the sound insulation effect on the noise generated by production equipment, prevent the impact of equipment noise on the Songjia Town Health Center, strengthen employees’ environmental awareness education, provide civilized production, and prevent artificial noise.

Solid waste impact analysis

The solid waste generated by this 3-4 t/h cat litter making machine in New Zealand project mainly includes domestic garbage and general industrial solid waste.

1. Domestic garbage
   The number of workers in this project is 10, and the domestic waste production coefficient is 0.5kg/person·day, so the domestic waste production volume is 1.5t/a, which will be uniformly removed and processed by the environmental sanitation department.
2. General industrial solid waste
   The general industrial solid waste generated by this 3-4 t/h cat litter making machine in New Zealand project is mainly waste packaging materials and dust collected by dust collectors.
   The amount of waste packaging materials produced is about 1.5t/a, and the amount of dust collected by the dust collector is about 1.44045t/a. After general industrial solid waste is collected, it is temporarily stored in the general solid waste warehouse in the factory area and is regularly sold centrally.

Environmental risk prevention measures and emergency requirements

Management measures

• Develop safety and fire prevention systems, operation specifications for each position, environmental management inspection system, etc., strictly implement various fire prevention, electricity safety and environmental risk prevention measures, strengthen safety education for employees, and teach fire extinguishing knowledge to employees in the 3-4 t/h cat litter making machine in New Zealand project area.
• Strict personnel management
  Human factors are often the main cause of accidents, so strict management and good human work are important links in preventing accidents.
  The main contents include: strengthening the risk awareness and environmental awareness education of employees in the project area, and enhancing safety and environmental awareness.
  Improve people's sense of responsibility and initiative; strengthen the job responsibility system of managers, strictly enforce various operating procedures and reward and punishment systems, and conduct systematic on-the-job training for operators so that each operator can be familiar with their job responsibilities and operating procedures; set up full-time or part-time environmental protection supervisory administrators are responsible for safety and environmental protection issues in the project area.
  They must frequently inspect accident-prone parts and locations to eliminate potential accident hazards, handle problems in a timely manner and report to relevant departments immediately if problems are discovered.
• Improve safety measures
  Perfect safety measures are an important part of ensuring safe operations. Implement full-person, full-process, and all-round safety management in the project area, and formulate safety management regulations and safety management measures.

Technical measures

• Process technology safety measures: Choose appropriate equipment and pipeline sealing materials to avoid leakage accidents; the project level must strictly implement national and industry standards, strictly implement relevant standards, and meet fire prevention and anti-seepage requirements; choose good quality valves and pipe fittings, Ensure long-term safe operation.
• All types of electrical equipment in the 3-4 t/h cat litter making machine in New Zealand project area shall use products with corresponding fire protection levels. Fire protection requirements are taken into consideration in the design of cable laying and distribution rooms.
  All electrical equipment in the 3-4 t/h cat litter making machine in New Zealand project area is of fire protection type, lightning protection and anti-static measures are designed, electrical equipment and lamps with corresponding fire protection levels are configured, and instruments are of quality and safety type.
• Each device in the project area shall be equipped with an automatic fire alarm system in accordance with the requirements of fire protection regulations and automatic fire alarm system design regulations. Once a fire hazard is discovered, an alarm signal is issued promptly, and operators should pay close attention to it and take timely remedial measures.

Why start a cat litter making machine in New Zealand?

Have you been looking for an environmentally friendly, sustainable, low-cost and highly profitable business opportunity? So, let’s explore this exciting field together – tofu cat litter!

Tofu cat litter, as the name suggests, is a cat litter made from tofu as the main raw material. Compared with traditional bentonite cat litter, tofu cat litter has better environmental performance because it can biodegrade and reduce environmental pollution. In addition, tofu cat litter is more hygroscopic and can better absorb cat urine, keep the cat toilet dry, and provide a healthier living environment for cats.

The cost of tofu cat litter is low, and the main raw materials are tofu residue and a small amount of additives. Due to the low cost of raw materials, the price of the tofu cat litter produced is relatively affordable. This will provide your business with greater profit margins.

As people's awareness of environmental protection increases, more and more people are paying attention to environmentally friendly products. As an environmentally friendly and healthy product, tofu cat litter is gradually becoming more and more popular among consumers. Therefore, producing and selling tofu cat litter will provide you with a broad entrepreneurial opportunity.

How to start a cat litter making machine in New Zealand?

First, you need to understand the production process and equipment of tofu cat litter. This can be achieved by attending relevant training courses or seeking professional help. Secondly, you need to find the right suppliers and establish a stable supply chain.

In addition, you also need to conduct market research to understand consumer needs and competitors in order to develop appropriate pricing and marketing strategies for your products.

Entrepreneurship Advantages and Prospects

There are many advantages to using tofu cat litter as a business venture.

• First of all, this product is highly competitive in the market due to its environmentally friendly properties.
• Secondly, due to its low cost and high profit characteristics, this project provides you with a large profit margin.
• Finally, as the pet market continues to expand, the market demand for tofu cat litter is also growing, providing broad development prospects for your business.

We are well aware of the hardships and risks of starting a business. Therefore, we provide comprehensive equipment processing and technical support services to help you quickly enter this industry.

Our professional team will provide you with guidance on production technology, equipment procurement, marketing and other aspects to help you successfully realize your entrepreneurial dream. In addition, we also provide high-quality after-sales service and stable supply chain support to ensure that your entrepreneurial journey is smoother.

Now, it's time to take action! If you are interested in this cat litter making machine in New Zealand project, please contact us today for more details. Richi Machinery will provide you with comprehensive support and guidance to help you take the first step towards success. Don't miss this rare entrepreneurial opportunity, let's work together to create a better future!
