3-4T/H Wood Pellet Production Line In Netherlands

Construction content and scale

The main construction content of this wood pellet production line in Netherlands project is to rely on the existing processing plant, dry material warehouse, finished product warehouse and other facilities, demolish the existing wet material warehouse, and build a new wet material warehouse to expand the storage capacity.

A new biomass pellet production line and supporting environmental protection facilities will be built. The labor quota for this project is 10 people, working 330 days a year and 8 hours a day.The composition of the project construction content is shown in the table below:

Consumption of main raw and auxiliary materials

The main raw and auxiliary materials consumption of this wood pellet production line in Netherlands project are shown in the following table:

Note: Sawn timber and wood chips are divided into dry material (moisture content 11%-20%) and wet material (moisture content 40%-50%), with wet material accounting for 20% and dry material accounting for 80%.

Main equipment for wood pellet line in Netherlands

The wood pellet production line in Netherlands project utilizes existing equipment such as crushers, wood granulators, screw conveyors and belt conveyors, eliminates existing dryers, and adds two new dryers to increase processing capacity, as follows: (Since the customer used some of the existing equipment and only replaced part of the main equipment and auxiliary equipment such as conveyors, boilers, air compressors, silos, etc., the investment amount of the project was relatively low.)

Details Of Machinery to Setup Wood Pellet Production Line In Netherlands

How to Set up Wood Pellet Production Line In Netherlands? The full process of a complete wood pelletizing plant, from biomass raw material processing to final packing biomass pellet, includes crushing, drying, pelletizing, cooling and packaging processes. Each process has corresponding equipment.

We break down the process into three processes and take a look at what equipment need to buy if you are planning to investing on wood pellet production line in Netherlands.

• Wood Chipping Machine: Making large wood like logs, tree limbs and trunks into <3mm thickness and 10-30 mm length wood chips.
• Wood Pellet Hammer Mill: Crushing the material into powder and making raw materials to the right size (below 3mm) for pelletizing process.
• Wood Sawdust Dryer: In general, the moisture content of raw material is still high after the pulverization from hammer mill, which is not suitable for pelleting. The dryer can make raw material moisture content to from 12% to 18%.
• Wood Fuel Pellet Machine: Press the mixed raw material into regular shape pellets by high pressure between the main parts roller and die. It is the soul of complete biomass wood pellet production line. According to the raw material and production needs of customers, choose suitable biomass pellets making machine are very important.
• Pellet Cooler: Pellet cooler is used to cooler the biomass wood pellets after pressed by the pellet machine. It is most commonly used in complete wood pellet production line.
• Pellet Packing Machine: It can weigh and pack the cooled pellets automatically. 10-50kg per bag is available to choose.

Highlights of Netherlands Wood Pellet Production Line

The remarkable feature of this 3-4tph wood pellet production line in Netherlands is that it adopts material mixing process, which realizes the stability of raw material entering pelletizing chamber and guarantees the continuous and stable running of equipments.

Compared to those pelletizing equipments made in USA or Germany, our wood pelletizing machines can endure a high material moisture content of 13-15%, so that customer can greatly lower the energy input in drying process, thus decreasing production cost.

Process design

1. Crushing 1:
   Wet sawn timber and wood chips with a moisture content of about 40%-60% are crushed by a crusher and then put into the wet material bin.
2. Drying:
   The project uses a wood dryer to dry the wet material. The drying equipment uses self-produced biomass pellets as fuel, and the hot air generated by combustion dries the wet material. After drying, the material enters the dry material bin through a closed pipe. The waste gas generated in this process includes fuel combustion waste gas and drying dust, which are collected and treated by a bag filter and discharged through a 20m exhaust pipe. The grass ash generated by the combustion of wood fuel pellets is a general solid waste and is sold as agricultural fertilizer.
3. Crushing 2:
   Dry sawn timber and wood chips with a moisture content of about 11%-20% are directly crushed by a crusher and then put into the dry material bin. The dust generated in this process is collected and treated by a bag filter together with the granulation dust and discharged through a 15m exhaust pipe.
4. Granulation:
   The dry material is transported to the wood biomass pellet machine through a closed screw conveyor. Strong pressure friction is generated between the material and the roller and template in the granulator, generating a large amount of heat, which heats the material to about 80°C and presses the material into biomass pellets.
5. Cooling and packaging:
   After the biomass wood pellets are naturally cooled, they are sent to the packaging area via a belt conveyor for packaging and sale. The dust generated in this process is collected and processed together with the crushing dust by a bag dust collector and discharged through a 15m exhaust pipe.

layout design

This wood pellet production line in Netherlands project is divided into a production workshop, a raw material area, a finished product warehouse, and an office and living area.

The production workshop is located in the middle of the factory area, the raw material area is located on the south side of the factory area, the finished product warehouse is located on the north side of the east side of the factory area, the living and office area is located on the southwest side of the factory area, and the factory entrance and exit are located on the west side of the factory area.

Starting Your Biomass Wood Pellet Production Business

Driven by the vigorous development of new energy, biomass energy utilization has gained widespread attention, and the biomass power generation industry is flourishing, showing the bright future prospect. a dn with the obvious progress of products and industries, biomass pellet making equipment has been being used in many aspects of our life.

Tips on Building Wood Pellet Production Line In Netherlands

Biomass wood energy has been the hot topic around the world, attracting more and more investors. Before starting wood pellet plant in Netherlands, you should make some preparation. Here are some tips:

• Market Researching
  Market decides if your biomass wood pellet production line can make profits and how much it will make. The first thing before building biomass wood pellet production line plant is to make market research. Such as, how many boilers can be used with pellets, how many people engaged in this industry, and if the local people know about biomass energy etc.
• Raw Materials
  In the biomass energy industry, who can take up the market if he has adequate raw material. Multiple kinds of raw materials can be used in biomass wood pellet press machine factory, like forestry waste, agro residues, living waste, animal waste etc. you should make sure the stable raw material resources.
• Production Factory Setup
  Building wood pellet production line factory in Netherlands is also important, which had better be close to the raw material resource. And the factory size should be decided in advance according to the scale of biomass wood pellet plant you want to setup.

Uses of wood pellets in Netherlands

• Civil boilers, fireplaces, industrial boilers: Along with the policy transformation of boilers and other equipment in many provinces and regions, coal burning is prohibited.
• Wood pellets made from wood pellet plant or biomass pellet factory are a good choice. So there is a market where boilers are used, such as chemical, paper, bathing centers, heating units and so on.
• Power generation plant.Biomass power generation has been developing rapidly in recent years, wood pellets are also a clock option, so you can go to the local power plant to see the market.
• Other uses, such as hardware baking paint, grain drying, baking tobacco, smelting financial aluminum, very wide.

The uses of wood pellets made from wood pellet production lines are very wide, the most common is the boiler, now a relatively large piece of the market. The biofuel market has a broad prospect, waiting for your development. When you have plans to start investing in a biomass wood pellet plant for biofuel wood pellet production business, please contact Richi Machinery for more information, we are always for you!

Depending on our years of experience, Richi Machinery divide biomass wood pellet production into many types. And our complete 0.3-60 ton/h wood pelletizing plant (with ring die pellet machine) from chipping to packing is CE certified by SGS. Welcome to contact us to get the latest cost to setup a complete pelletizing plant for business or individual use!

Buy wood pellet production line from biomass pellet equipment manufacturer or supplier at factory price, get FREE technical instruction of biomass pellet process and business plan to set up biomass wood pellet production line project in Netherlands, German, Australia, Romania, United States, The Czech Republic, Guatemala, South Korea, Japan, Thailand, Indonesia, etc., at low cost.

Huge demand for wood pellet manufacturing in the Netherlands

In 2023, Dutch wood pellet imports reached a new high, totaling $711 million. The United States was the leading non-European Union (EU) supplier to the Netherlands. Wood pellet-generated energy is estimated to have accounted for approximately ten percent of total Dutch renewable energy use last year. In the future, the Dutch government will place more emphasis on the use of biomass for higher value applications.

Currently the government is in the process of implementing the EU's second Renewable Energy Directive (REDII) in Dutch Law, and is planning to add socio-economic criteria to the sustainability criteria of the REDII. It can be clearly seen that the wood pellet manufacturing business in the Netherlands is very promising because of the huge domestic demand.
